The Furuno DT-800MSF Bronze TH NMEA2000 Depth And Temp is a compact, bronze-depth and temperature sensor designed for boats on NMEA2000 networks. It delivers quick, dependable depth and water-temperature data to support navigation and safety in saltwater conditions.
-
Integrated depth and temperature sensor: Depth sensing (0.5 m minimum) and temperature measurement in a single bronze housing.
-
Bronze housing: Durable, corrosion-resistant construction designed for saltwater environments.
-
Fast-response temperature sensor: ±0.2°C (±0.1°F) accuracy for quick, reliable readings.
-
235 kHz transducer element: Broadband Ceramic Technology for improved resolution without sacrificing sensitivity.
-
Power and performance: 100 W RMS power rating supports depth performance across varying conditions.
-
Data update rate: 1 update per second for timely readings.
-
Depth range: Minimum sounding depth 0.5 m; maximum sounding depth 180 m (600 ft).
-
Pressure rating: 3 m (10 ft) rating for typical marine installations.
-
Pulse rate: 20,000 pulses per nautical mile (5.6 Hz per knot) for precise range measurements.
-
Smart Sensor: Integrated sensing technology designed to operate efficiently within the specified power envelope.
-
Electrical requirements: Supply voltage 10 VDC to 25 VDC; supply current 40 mA at 100% power.
-
Connectivity: Standard cable length 6 m; NMEA 2000 LEN 4 for network integration.
-
Acoustic window: Urethane acoustic window for signal clarity and durability in marine environments.
-
Weight: 1.5 kg (3.4 lb).
The DT-800MSF simplifies installation by combining depth and temperature sensing on a single, robust bronze unit. Its fast temperature response and high-resolution 235 kHz transducer enable more confident depth positioning in both shallow and deep water. With NMEA 2000 compatibility (LEN 4) and a practical 6 m cable, it integrates smoothly into existing marine networks, reducing clutter and setup complexity. The bronze housing and urethane acoustic window are built to endure saltwater conditions, helping ensure dependable reading accuracy over time. A reliable 1-second data update supports timely decisions for navigation and safety.
Weight| 1.5 kg (3.4 lb) |
| Data Update Rate |
1 per second |
| Minimum Sounding Depth |
0.5 m (1.6 feet) |
| Maximum Sounding Depth |
180 m (590 feet) |
| Pressure Rating |
3 m (10 feet) |
| Pulse Rate |
20,000 p/nm* (5.6 Hz per knot)-*p/nm = pulses per nautical mile |
| Smart Sensor Supply Voltage at 100% Sound Power Output |
10 VDC to 25 VDC |
| Supply Current |
40 mA S |
| tandard Cable Length |
6m |
| NMEA 2000(R) Load Equivalency Number (LEN) |
4 |
