Powerwinch Free Fall Windlass 750 Lbs To 36'

Save 28%

Part number
P77736
UPC
033936777364
Condition
Brand new
Shipping
Free shipping · Ships same business day when ordered by 4 PM ET
Price:
Sale price$950.99 Regular price$1,324.49
Stock:
Only 2 units left
Same-day shippingIn-stock orders by 4 PM ET
30-day returnsHassle-free returns
Secure checkoutShop Pay, PayPal & all major cards
BBB A+ accreditedFamily-run in Powell, TN

Questions about fit or setup? Call 865-607-9472

BBB A+ Accredited Business

Description

Powerwinch "Class 36" Free-Fall Anchor Windlass

Fastest way to anchor - Anchor drops up to four times faster! Easiest way to anchor - Free-Fall stops when the anchor has reached bottom - Rope does not collect on your deck while you waste time and effort powering down. Easiest to use - just hold the helm switch for only five seconds to release free-fall, versus one to three minutes powering down. Safety - Allows you to anchor quickly in poor conditions. Precise anchoring location - Anchor your boat where you want it to be, unlike powering down where your boat will drift while you power down.

Powerwinch offers durable and smooth Free-Fall Anchor Windlass. Their free fall system allows the anchor to fall at a rate of up to 300' per minute. Easily four time faster than powering down. The gear systems are oil impregnated with heat treated oil. Stainless steel drive shafts give years of smooth and reliable performance. A tapered splice is ideal for smooth rope-to-chain transition. The motor plate is made of one piece which provides improved gear life and and smooth power transmission. The smooth motor uses less amps by not needing the battery power during free-fall. Watertight sealed stainless sealed fasteners are easy to remove and have excellent corrosion resistance.

Features:

  • Unit Weight 22 lbs
  • Retrieval Speed 80' / minute
  • Line Size 1/2" Powerwinch Premium Medium Lay Nylon
  • Overall Dimensions 10-9/16" L x 7" W x 6-5/16" H
  • Pulling Power 775 lbs
  • Avg. Amp Draw (during retrieval) 8-12 amps
  • Anchoring Speed Up to 250' per minute
  • Chain Size 1/4" Hi-test ACCO G4
  • Rodes (sold separately) P10293-P10296
  • Rope & Chain System Electro-Plated Stainless Steel
  • Replaceable Rode-Glide Engineered Resin
  • Includes: Helm Operated Control Switch Rocker and 25 AMP Thermal Circuit Breaker

Click here to download Powerwinch Free-Fall Anchor Windlass

Required Materials Not Included with Powerwinch Class 36 Freefall Anchor Windlass

Below is a chart outlining the materials you will need IN ADDITION to buying your windlass. The following are required for an electrical installation:

Qty. Description
 2 ft  12 awg RED Wire Class 105°C
2 ft    12 awg BLACK Wire Class 105°C
70 ft    6 awg RED Wire Class 105°C 6 awg wire is the "run" wire from anchor to switch and battery to switch. Length is based on instalation
70 ft    6 awg BLACK Wire Class 105°C
10   5/16" 6 awg ring terminals
4  5/16" 12 awg ring terminals
4  1/4" 12 awg insulated female spade quick disconnects
6   1/4-20 x 1/2 Screws   Screws and nuts should be stainless steel to avoid rust and corrosion.
6  1/4-20 Nuts
   Wire Ties
2 ft  1" diameter heat shrink
 2 ft  2" diameter heat shrink
