The Victron ANL-Fuse 500A/80V is a bolt-down, fast-acting fuse built to protect high-current 48V power circuits. It provides robust, reliable overcurrent protection for critical 48V installations.
-
Max current rating: 500 A
-
Max voltage rating: 80 V
-
Type: Bolt-down, fast-acting fuse
-
Designed for: 48V systems
-
Low voltage drop: ~100 mV
-
Cold resistance: 0.25 mΩ
-
Package contents: 1 × ANL fuse
-
Manufacturer: Victron Energy
-
Manufacturer Part No: CIP142500000
-
Protection capability: High short-circuit breaking capacity for demanding 48V installations (outperforms MEGA fuses in some setups)
This fuse provides high short-circuit breaking capacity, protecting your 48V circuits from damaging overcurrent events. Its bolt-down design enables straightforward installation, while a minimal voltage drop and very low cold resistance help conserve system efficiency during continuous operation. With a dedicated 500 A/80 V rating, it’s well suited to safeguard 48V power products and components in a compact, single-fuse package.
