Meet the Victron Orion-TR DC-DC Converter, a compact isolated power module that converts 48 VDC input to 24 VDC output at up to 16 A (380 W nominal, 430 W at 25°C). Built for reliability in demanding environments, it provides true galvanic isolation between input and output, reducing ground loop issues and protecting sensitive electronics.
Key benefits
-
Isolated and paralleled capable: galvanic isolation and an unlimited number of units can be connected in parallel to increase output current.
-
Remote On/Off: Separate minus (-) leads and a remote on/off terminal that eliminates the need for a high-current switch in input wiring; control via a low-power switch or engine run/stop switch.
-
Robust protection: high-temperature protection with current derating; IP43 protection when terminals are oriented downward; short-circuit protected (40 A peak).
-
Flexible output: adjustable output voltage from 20 to 30 V with a nominal 24.2 V, tolerance ±0.2 V, and low noise (2 mV rms).
-
Durable, easy to install: screw terminals (no special tools), input fuse on 12V/24V models (non-replaceable), compact 130 x 186 x 70 mm, 1.6 kg.
Note: This converter is not intended for battery charging. For charging applications, Victron recommends the Orion-Tr Smart series.
Technical specifications at a glance
-
Input voltage range: 40–70 V DC
-
Under/Over voltage: UV shut down 28 V, UV restart 30 V
-
Output: 24.2 V nominal; adjustable 20–30 V; tolerance ±0.2 V; noise 2 mV rms
-
Current: 16 A continuous at nominal output / 25 A max for 10 s / 40 A short circuit
-
Power: 430 W continuous at 25°C; 380 W at 40°C
-
Efficiency: ~89%
-
Isolation: 200 V DC between input, output, and case
-
Operating temp: -20 to +55°C (derate 3%/°C above 40°C)
-
Humidity: up to 95% non-condensing
-
Connections: screw terminals; max cable 16 mm²
-
Size/Weight: 130 x 186 x 70 mm; 1.6 kg
-
Safety/Compliance: EN 60950; emissions/immunity EN standards; automotive R10-5
Manufacturer: Victron Energy | Model: ORI482441110
