Take charging precision to the next level with the Victron Skylla - 24/100 TG Charger - 230V. This rugged charger delivers one full-rated output plus an additional 4 A output, engineered for reliable performance across large battery banks. The charge voltage can be precisely adjusted to suit any sealed or unsealed battery system, helping protect long-term battery life and optimal performance.
Charge management is intelligent and flexible: the voltage can be measured directly at the battery terminals to compensate for voltage loss along cables, and an external temperature sensor allows real-time temperature-based voltage compensation. This ensures safe, efficient charging in a variety of operating conditions.
With a microprocessor-controlled three-stage charging process, TG Chargers deliver consistent, accurate charging whether you’re using AC or DC supply (AC-DC and DC-DC operation). The Skylla incorporates a battery temperature sensor that automatically adjusts charge voltage as temperatures rise, preventing overcharge and gassing. A dedicated voltage sensor compensates for cable resistance so the battery always receives the correct charge voltage, preserving battery health and extending service life.
Key features
-
One full-rated output plus one 4 A output for flexible charging of large battery banks
- Precisely adjustable charge voltage for any sealed or unsealed battery system
- Direct terminal voltage measurement to offset cable losses
- External battery temperature sensor for automatic temperature-compensated charging
- Microprocessor-controlled three-stage charging for optimal performance
- Can function as a stabilized power supply when batteries or large buffers are not available
- Supports both AC-DC and DC-DC operation for versatile installations
Technical specifications
-
Input Voltage: 230V AC
-
Input Voltage Range: 185 to 264 VAC; 180 to 400 V DC
-
Battery Capacity: 500 to 1000 Ah
-
Frequency: 45 to 65 Hz
-
Battery Connection: M8 studs
-
230V AC Connection: Screw clamp (AWG 6)
-
Dimensions (H x W x D): 14.4" x 9.9" x 10.1" (36.5 x 25 x 25.7 cm)
-
Weight: 22 Lbs (10 kg)
In the box
- Charger
- Mounting brackets
- Temperature sensor with 4.9' (1.5 m) wire
- Instruction manual
Sold as an individual unit. Please contact your dealer for any returns, repairs or support issues related to this product.
Manufacturer: Victron Energy • Part No: SDTG2401001 • UPC: 8719076025788
