Power your RV, boat, or off-grid system with the Xantrex Freedom X2000 24V True Sine Wave Inverter. This compact, lightweight unit delivers reliable 2000 W of continuous power with a robust 4000 W surge, providing clean, stable AC for refrigerators, microwaves, and other sensitive or motor loads. With true sine wave output, it protects electronics and ensures smooth startup of inductive appliances.
Key Features
-
True Sine Wave Power: Delivers clean, stable 120 VAC power for all sensitive electronics, motors, and appliances.
-
High Surge Capacity: Surges to 4000 W for 2 seconds to start demanding loads like refrigerators and microwaves.
-
24V DC Input, 120V AC Output: Converts 24 VDC to a reliable 120 VAC supply for household-grade appliances.
-
Ignition Control: Turn the inverter on/off via a 24 VDC signal and minimize battery drain when the ignition key is turned off.
-
Wide Input Range: 20–32 VDC input to accommodate high-voltage alternators found on many vehicle chassis.
-
Built-in 30A AC Transfer Relay: Automatically transfers the load to shore or generator when AC is available, and back to inverter when not.
-
Quick Installation: Large wiring bay and quick-connect AC IN/OUT terminals for fast, easy wiring.
Performance and Specs
-
Continuous Power: 2000 W @ 40°C
-
Surge Power: 4000 W (2 seconds)
-
Output: 120 VAC, 60 Hz (nominal)
-
Efficiency: Peak 91%; Full-load ≥86%
-
Operating Voltage Range: 85–140 VAC
-
DC Input: 20.0–31.0 VDC (nominal 24 VDC); max non-operating 50.4 VDC
-
Operating Temperature: -4 to 140°F (-20 to 60°C); derates above 104°F (40°C)
-
Storage Humidity: 5–95% RH, non-condensing
-
Transfer Relay Rating: 30 A DC
-
Dimensions (L×W×H): 14.6" × 10.8" × 3.9" (without flanges); with flanges, 14.6" × 12.0" × 3.9"
What’s in the Box
- Freedom X unit
- Pre-installed ground lug
- Documentation
Whether you’re outfitting an RV, boat, or off-grid cabin, the Xantrex Freedom X2000 delivers premium power in a compact package. Built to operate across a wide temperature range and climates, it keeps running when you need it most, with safe operation and simple installation.
| Electrical Specifications |
| Operating voltage |
120, 110, 108 VAC |
| Continuous power |
Continuous Power 2000 W @40 C True sine wave |
| Continuous current |
16.7 Amps |
| Surge power |
4000 watts |
| Frequency |
60 Hz |
| Peak efficiency |
91% |
| Full load efficiency |
Greather than or equal to 86% |
| Operating voltage range |
85-140 VAC |
| Safe Non-Operating voltage range |
Up to 240VAC |
| General Specifications |
| Operating temperature range |
-4 to 140 F (-20 to 60 C), with output derated above 104 F (40 °C) |
| Storage Temperature Range |
-40 to 158 F (-40 to 70 C) |
| Humidity |
5 to 95% RH, non-condensing |
| Transfer Relay Rating |
30Amp |
| DC Input Operating voltage range |
20.0 - 31.0 Vdc |
| DC Input Max Non-Operating Voltage |
50.4 Vdc |
| DC Input Nominal Voltage (Inverting) |
24.0 Vdc |
| DC Nominal Current at Full Load |
86 ADC |
| L x W x H (Without Mount Flanges) |
14.6"(370mm) x 10.8"(275mm) x 3.9"(100mm) |
| L x W x H (With Mount Flanges) |
14.6"(370mm) x 12.0"(305mm) x 3.9"(100mm) |
