The Xantrex Freedom XC PRO 2000 Marine Inverter Charger is a compact, all‑in‑one power solution designed for boats and off‑grid setups. It delivers true sine‑wave AC, 2000 W of continuous power, and a built‑in lithium‑ion charger in a lightweight package. Model 818‑2015 extends your capabilities with motor‑friendly surge and seamless integration with modern vessel systems.
-
Inverter Power & Waveform: 2000 W continuous power with true sine wave and a 4000 W surge for up to 5 seconds; 60 Hz or 50 Hz configurable; 120/110/108 VAC output; 16.7 A continuous current.
-
Motor‑friendly Surge: Extended surge capability to start compressors, fridges, and other motor‑driven equipment without dropping loads.
-
Integrated Input & Ignition Control: Wide input range (10.1–18.0 VDC); ignition control turns the inverter on/off via a 12 V signal to minimize battery drain when the ignition is off.
-
Built‑in Lithium‑Ion Battery Charger: 100 A dedicated charging current (selectable 5–100 A) with PF‑corrected charging and an output up to 18.0 V to support modern battery chemistries.
-
Three‑Stage, Temperature‑Compensated Charging: Optimizes charging for various battery types up to 18 V, with temperature compensation to maximize performance and longevity.
-
Battery Health Features: Includes battery equalization to maximize flooded battery life and Dead Battery Charging to 0 V for recovery in critical situations.
-
Power Share & Efficiency: Prioritizes AC loads by reducing charge current to keep total input current under the breaker setting; peak efficiency 91%, full load efficiency ≥86%.
-
System Integration: Integrated inverter, charger, and transfer switch in one compact footprint; NMEA 2000 / CANbus compatibility for smarter vessel power management (Micro‑C CANbus support).
-
Remote Monitoring & Control: Bluetooth monitoring via the optional remote panel (model # 808‑0817‑02) to configure and monitor performance.
-
All‑Weather Operation: Operates from -4°F (-20°C) to 104°F (40°C) with full output in invert or charge mode for dependable performance at sea.
-
Dedicated Charger Specification: 100 A dedicated charger for the 2000 W model (150 A on higher models), with configurable DC output up to 18 V and up to 100 A charging current.
This all‑in‑one design reduces installation clutter while delivering reliable, efficient power for marine electronics, appliances, and critical systems. With true sine‑wave output, smart charging, and vessel‑level integration, you can power sensitive devices, preserve battery health, and manage power strategically even when boat systems are running. The built‑in transfer switch, remote monitoring option, and wide operating temperature range keep your setup resilient in variable marine conditions.
| ELECTRICAL SPECS - INVERTER |
| AC Output Operating Voltage Options |
120, 110, 108 Vac |
| Continuous Output Power |
Continuous Power 2000 W @40 C True sine wave (TSW) |
| Continuous AC Output Current |
16.7 A |
| Surge Power |
4000 W (? 5 sec) |
| Frequency (Configurable) |
60 (or 50) Hz |
| Peak Efficiency |
91% |
| Full Load Efficiency |
gretaer than or equal to 86% |
| DC Input Operating voltage range |
10.1 - 18.0 VDC |
| DC Input Max Non-Operating Voltage |
25.2 Vdc |
| DC Nominal Current at Full Load |
192 Adc |
| ELECTRICAL SPECS - BATTERY CHARGER |
| Min Battery Voltage for Charging |
0.0 Vdc |
| Max DC Output Voltage |
18.0 Vdc (custom battery type) |
| Selectable DC Output Current |
User Selectable: 5 - 100 A |
| Full Load Max AC Input Current |
24 Arms |
| Max DC Charge Current (selectable down to 5A) |
100A |
| Operating Input AC Pass-Through Voltage Range |
85-140 Vac |
| Safe Non-Operating Input AC Voltage Range |
Up to 240 Vac RMS |
| Power Factor at Full Charge Rate |
> 98% |
| GENERAL SPECS |
| Operating Temperature Range |
4 to 140 F (-20 to 60 C), with output derated above 104 F (40 °C) |
| Storage Temperature Range |
-40 to 158 F (-40 to 70 C) |
| Operating Humidity Range |
5 to 95% RH, non-condensing |
| Transfer Relay AC Current Rating |
30 A surge, 24 A continous |
| DC Input/Output Nominal Voltage (inverting/ Charging) |
12.0 Vdc |
| L x W x H (without flanges) |
15.4"(390 mm) x 10.8"(275 mm) x 4.9"(125 mm) |
| L x W x H (with flanges) |
16.0"(406 mm) x 12.0"(305 mm) x 4.9"(125 mm) |
